DOWNLOAD COMPLETE PDF FOR AGCO ALLIS PLANTER 385 PULL TYPE TOOL BAR 4 6 8 AND 12 ROW SPARE PARTS CATALOGUE MANUAL - 79010158 - PDF FILE

SCOPRI IL MANUALE DI RICAMBI PER IL BARRA DI ATTREZZI AGCO ALLIS PLANTER 385, DISPONIBILE IN FORMATO PDF. QUESTO CATALOGO DETTAGLIATO INCLUDE INFORMAZIONI ESSENZIALI PER LE VERSIONI A 4, 6, 8 E 12 FILE, GARANTENDO CHE TU POSSA FACILMENTE IDENTIFICARE E ORDINARE I PEZZI DI RICAMBIO NECESSARI PER MANTENERE IL TUO ATTREZZO IN PERFETTE CONDIZIONI. OTTIMIZZA LA TUA OPERATIVITÀ AGRICOLA CON QUESTO STRUMENTO INDISPENSABILE PER OGNI PROFESSIONISTA DEL SETTORE.

PART NUMBER :
79010158

MODEL COVERED :
AGCO ALLIS 385 PLANTER
APPLICABLE MODELS: 4 ROW, 6 ROW, 8 ROW, 12 ROW

MANUAL CONTENT :
FRAMES – MAIN FRAME & HITCH, PULL TYPE, 4, 6 & 8 ROW
FRAMES – MAIN FRAME, TRUSS & HITCH, 12 ROW (PRIOR S N 5001)
FRAMES – MAIN FRAME, TRUSS & HITCH, 12 ROW (EFF. S N 5001)
FRAMES – TOOL BAR, HITCH & PARKING STAND, TOOL BAR
FRAMES – OFFSET HITCH, TOOL BAR, 4, 6 & 8 ROW
FRAMES – HITCH BEAM & PARKING STAND, 12 ROW
FRAMES – ROW MARKERS, 144 & 180 PULL TYPE FRAMES, 140,
FRAMES – ROW MARKERS,240 PULL TYPE FRAME,230 TOOL BAR FRAME
FRAMES – ROW MARKER, 360 FRAME, 12 ROW (PRIOR S N 5001)
FRAMES – ROW MARKER, 12 ROW (EFF. S N 5001)
FRAMES – TRANSPORT AXLE & WHEEL, DRIVING, NON-DRIVING & FLOAT
FRAMES – TRANSPORT AXLE & WHEEL, TOOL BAR PLANTER
FRAMES – ROAD TRANSPORT AXLE & WHEEL
FRAMES – PLANTING UNIT
FRAMES – WEIGHT BRACKETS, PRIOR – PULL TYPE
DRIVES – MAIN DRIVE, PULL TYPE
DRIVES – TRANSMISSION, PULL TYPE
DRIVES – TRANSMISSION, TOOL BAR
DRIVES – UNIT DRIVE, AIR PLANTER
DRIVES – UNIT DRIVE, PLATE PLANTER
DRIVES – FERTILIZER DRIVE, PULL TYPE
DRIVES – CHEMICAL APPLICATOR
DISKS & PLANTING WHEELS – DISK FURROWER
DISKS & PLANTING WHEELS – NO-TIL COULTERS
DISKS & PLANTING WHEELS – PLANTING UNIT, 16 OPENER DISK ASY.
DISKS & PLANTING WHEELS – PLANTING UNIT
DISKS & PLANTING WHEELS – PLANTING UNIT, FIRMING WHEEL
DISKS & PLANTING WHEELS – FERTILIZER OPENER, 16 DOUBLE DISK
ELECTRICAL – BLOWER
ELECTRICAL – BLOWER CONTROL
ELECTRICAL – WIRING
HOPPERS & HOUSINGS – SEED DISK HOUSING, AIR PLANTER
HOPPERS & HOUSINGS – SEED HOPPER, AIR PLANTER
HOPPERS & HOUSINGS – SEED HOPPER, W INSECT. & HERB. OPTIONS
HOPPERS & HOUSINGS – SEED PLATE HOUSING, PLATE PLANTER
HOPPERS & HOUSINGS – CHEMICAL METER,W INSECT. & HERB. OPTIONS
HOPPERS & HOUSINGS – FERTILIZER HOPPERS, PULL TYPE
HOPPERS & HOUSINGS – TANK & FITTINGS, LIQUID FERTILIZER
HYDRAULICS – HYD. CYLINDERS, ROW MARKERS, 4 & 6-ROW UNITS
HYDRAULICS – HYDRAULIC CYLINDERS, ROW MARKERS, 12 ROW UNITS
HYDRAULICS – LIFT CYLINDERS, 2.75 X 8, 3 X 8, 3.25 X 8
HYDRAULICS – HYD. CYLINDER, HITCH SWING & CROSS AXLE LIFT
HYDRAULICS – HYDRAULIC LINES, WHEEL LIFT, 4, 6 & 8 ROW
HYDRAULICS – HYDRAULIC LINES, WHEEL LIFT, DRIVING
HYDRAULICS – HYDRAULIC LINES, ROW MARKERS, 4, 6 & 8 ROW
HYDRAULICS – HYD. LINES, ROW MARKER, 12 ROW PRIOR S N 5001
HYDRAULICS – HYD. LINES, ROW MARKER, 12 ROW EFF. S N 5001
HYDRAULICS – HYD. LINES, HITCH SWING, 12 ROW PRIOR S N 5001
HYDRAULICS – HYD. LINES,CROSS AXLE LIFT,12 ROW PRIOR S N 5002
HYDRAULICS – HYDRAULIC LINES, HITCH SWING & CROSS AXLE LIFT
PUMPS – SQUEEZE PUMP & HOSES, LIQUID FERTILIZER
DECALS

SIZE : 4.41 MB
TOTAL PAGES : 116
FORMAT : PDF
LANGUAGE : ENGLISH
DOWNLOAD INFORMATION - YOU WILL RECEIVE THE DOWNLOAD LINK ON YOUR GIVEN E-MAIL.
